VIPER26H PWM IC

Первоначальная цена составляла $0.99.Текущая цена: $0.95.

VIPER26H VIPER26HDTR

  • Дата доставки: Отправка в течение 3 дней после полной оплаты.
  • Способ оплаты: Банковский перевод | БТД | USDT (ERC20/TRC20)

Поддержка оптового заказа и предложения других частей

 WhatsApp: +8618124018244

Описание

Original VIPER26HDTR Marking VIPER26H PWM Power management chip Controller for PSU WhatsPower

The VIPER26 device is a smart high voltage converter that integrates an 800 V avalanche-rugged power MOSFET with PWM current mode control. The power MOSFET with 800 V breakdown voltage allows an extended input voltage range to be applied, as well as the size of the DRAIN snubber circuit to be reduced. This IC meets the most stringent energy-saving standards with very low consumption and burst mode operation under light load.

The design of flyback, buck and buck boost converters is supported. The integrated HV startup, sense-FET, error amplifier and oscillator with jitter allow complete application designs with a minimum number of components.

Функции
• 800 V avalanche rugged power MOSFET allowing wide range VAC input range to be covered
• Embedded HV startup and sense-FET
• Current mode PWM controller
• Minimized system input power consumption:
– Less than 30 mW @ 230 VAC in no-load condition
– Less than 400 mW @ 230 VAC with 250 mW load
• Limiting current with adjustable set point
• Jittered switching frequency to reduce the EMI filter cost:
– 60 kHz ±4 kHz (L type)
– 115 kHz ±8 kHz (H type)
• Embedded error amplifier
• Hysteretic thermal shutdown
• Built-in soft-start for improved system reliability
• Protections with automatic restart: overload/short-circuit (OLP), feedback loopdisconnection

Применение
• Auxiliary power supply for appliances
• Power metering
• LED drivers
• SMPS for set-top boxes, DVD players and recorders

Детали

наименование товара

VIPER26HDTR Marking VIPER26H

Тип крепления

Поверхностное крепление

Пакет/кейс

16-SOIC (0.154", 3.90mm Width)

Рабочая Температура

-40°C ~ 150°C (TJ)

Power (Watts)

20 W

Frequency - Switching

115kHz

Duty Cycle

70%

Voltage - Supply (Vcc/Vdd)

11.5V ~ 23.5V

Voltage - Breakdown

800V

Output Isolation

Either
